Vergleichstabelle Kraftmessgeräte der Serie M7, M5, M4, M3, M2




Vergl.-Tabelle Serie 7,5,4,3,2, DE




  • 7.000 Hz Übertragungsrate
  • USB, RS-232, Mitutoyo, und analog Ausgang
  • ±0.1% Genauigkeit
  • 1.000 Messwerte Datenspeicher für Statistiken
  • Kapazitäten: von 0,5N bis 5000 N



Kraftmessgerät Serie M4
  • 3.000 Hz Übertragungsrate
  • USB, RS-232, Mitutoyo, und analog Ausgang
  • ±0.2% Genauigkeit
  • 50 Messwerte Datenspeicher für Statistiken
  • Reversierbares Gehäuse und Display
  • Kapazitäten: von 0,5N bis 2500 N

  • 2,000 Hz Übertragungsrate
  • Ultra-Kompaktes Gehäuse
  • USB Ausgang
  • ±0.3% Genauigkeit
  • Reversierbares Gehäuse und Display
  • Kapazitäten: von 0,5N bis 2500 N



Kraftmessgerät Serie M2
  • 500 Hz Übertragungsrate
  • Ultra-Kompaktes Gehäuse
  • ±0.5% Genauigkeit
  • Reversierbares Gehäuse und Display
  • Kapazitäten: von 10 N bis 500 N


Kraftmessgeräte_Vergleichstabelle.pdf 255.65 KB
Comparison_Chart-Series5-4-3.pdf 100.36 KB


Die folgende Tabelle fasst die technischen Eigenschaften der Mark-10 Kraftmessgeräte.



  Serie M5
Serie M4 Serie M3
Accuracy (FS ±1 digit): ±0.1% ±0.2% ±0.3%
Sampling rate: 7,000 Hz 3,000 Hz 2,000 Hz
Resolution: 1/5,000 1/2,000 1/1,000
Data outputs: USB, RS-232, Mitutoyo, Analog USB, RS-232, Mitutoyo, Analog USB
Programmable auto output via USB/RS-232: Yes No No
MESURTM Lite software included: Yes Yes Yes
Data output functionality: By pressing DATA button, or requesting from a PC or other device By pressing DATA button, or requesting from a PC or other device (currently displayed reading only) By pressing DATA button, send current reading only. Cannot request externally.
ASCII command set for external control (Gauge Control Language 2): Full command set "?" only
(request current reading)
None
Communication with MESURTMgauge and MESURTM Lite: Full communication Send data from gauge or request from software (single readings or continuous readings) Send current (single) readings only, cannot request from software
Communication with ESM301 test stand and Series DC controllers: Full communication, including PC control Stop/reverse at force set points, overload protection, and communication through the “?” character only None
Data memory: 1,000 readings with output, with individual data point deletion, or clear all 50 readings with output, with individual data point deletion, or clear all. No
Statistics calculations and output to PC: Yes Yes N/A
Averaging mode: Yes No No
External trigger mode: Yes No No
Analog load bar graph shown on display: Yes Yes Yes
On-screen set point (pass/fail) indicators: Yes, with markers on analog load bar graph Yes, with markers on analog load bar graph Yes, with markers on analog load bar graph
Display: Graphic, backlit LCD, with backlight auto-off Graphic, backlit LCD, with backlight auto-off Graphic, backlit LCD, with backlight auto-off
Password protection: Yes, for calibration and individual keys No No
Peak readings always displayed: Yes Yes Yes
Set points: High / low indicators, with output (dedicated pins for high and low) High / low indicators, with output (dedicated pins for high and low) High / low indicators,
no output
Programmable audible tones (beeps): Yes Yes Yes
Certificate of calibration: NIST-traceable with data (10 points in each direction) NIST-traceable with data (10 points in each direction) NIST-traceable without data (data is available for an additional charge)
Configurable calibration (weight increments and no. of data points): Yes Yes Yes
Overload outputs: Dedicated pins for tension and compression Dedicated pins for tension and compression No
No. of units of measurement: 5 5 3
Capacity range /
no. of capacities:
0.12 lbF – 1000 lbF
[0.5 N - 5000 N] / 12
0.12 lbF – 500 lbF
[0.5 N - 2500 N] / 11
0.12 lbF – 500 lbF
[0.5 N - 2500 N] / 11
Reversible housing: Yes Yes Yes
Dimensions: 2.5 x 5.9 x 1.3 in.
[64 x 150 x 33 mm]
2.5 x 5.9 x 1.3 in.
[64 x 150 x 33 mm]
2.5 x 3.9 x 1.5 in.
[64 x 99 x 38 mm]
Preise in €






Kraft / Drehmoment Anzeigegeräte VERGLEICHSTABELLE

Die folgende Tabelle fasst die technischen Eigenschaften der Mark-10 Kraft / Drehmoment- Anzeigegeräte.




  Modell 5i Modell 3i
Accuracy (FS ±1 digit): ±0.1% ±0.2%
Senor password protection: Yes No
Sampling rate: 7,000 Hz 2,000 Hz
Resolution: 1/2,000 / 1/1,000, depending on sensor 1/1,000
Data outputs: USB, RS-232, Mitutoyo, Analog USB
Programmable auto output via USB/RS-232: Yes No
MESURTM Lite software included: Yes Yes
Communication with Series DC test stand controllers: Full communication, including PC control None
Data Memory Full command set None
Communication with MESURTMgauge and MESURTM Lite: Full communication Send current (single) readings only, cannot request from software
Communication with ESM301 test stand and Series DC controllers: Full communication,
including PC control
None
Data memory: 1,000 readings, with output No
Data memory deletion: Any individual data point, or clear all N/A
Statistics calculations and output to PC: Yes N/A
Averaging mode: Yes No
External trigger mode: Yes No
Analog load bar graph shown on display: Yes Yes
Set points (for pass/fail indication): Yes, with high/low indicators, markers on analog load bar graph, and outputs Yes, with high/low indicators, markers on analog load bar graph, no outputs
Display: Graphic, backlit LCD, with backlight auto-off Graphic, backlit LCD, with backlight auto-off
Keypad password protection: Yes, for calibration and individual keys No
Peak readings always displayed: Yes Yes
Programmable audible tones (beeps): Yes Yes
Certificate of calibration: Yes, NIST-traceable with Yes, NIST-traceable
Configurable calibration (weight increments and no. of data points): Yes Yes
Overload outputs: Dedicated pins for tension and compression No
No. of units of measurement: 5 3
Reversible housing: Yes No
Dimensions: 2.5 x 5.9 x 1.3 in.
[64 x 150 x 33 mm]
2.5 x 3.9 x 1.5 in.
[64 x 99 x 38 mm]
Preise in €
